H Beams, also known as H-section steel or steel H beams, are structural steel beams with an “H” shape. They are widely used in construction and various industrial applications due to their strength and versatility. H Sections are distinguished by their characteristic shape, which resembles the letter “H” from the cross-section.
Shree Ji Steel Private Limited (formerly Shree Ji Steel Corporation), is a well-known company in the steel industry that provides high-quality Beam H. With their expertise and experience, they have become a trusted supplier and distributor of the best quality Beam H.
Steel H Beam offer several advantages in construction projects. Their design allows for optimal load-bearing capacity, making them suitable for supporting heavy loads. They are commonly used in the construction of buildings, bridges and other structures where strength and stability are crucial.The manufacturing process of H Section Steel ensures that the beams have consistent dimensions and excellent structural integrity. These are typically made from carbon steel or alloy steel, which provides durability and resistance to various environmental conditions.It can support both vertical and horizontal loads. Their wide flanges and strong web allow for efficient distribution of weight, making them ideal for spanning long distances. Additionally, H beams can be easily connected and joined together, enabling flexibility in design and construction.
Shree Ji Steel Corporation offers a wide range of Beam HÂ in different sizes, lengths and specifications, ensuring that clients can find the perfect solution for their projects. The company is committed to delivering superior quality products, adhering to stringent industry standards and regulations.
ITEAM NAME | SIZE | PRICE | UNIT |
---|---|---|---|
MS H BEAM | 100x116mm(20KG) | ₹50,011 | Per Ton |
MS H BEAM | 100x116mm(23KG) | ₹49,811 | Per Ton |
MS H BEAM | 125x70mm(11KG) | ₹50,511 | Per Ton |
MS H BEAM | 125x70mm(12KG) | ₹50,011 | Per Ton |
MS H BEAM | 125x70mm(13.3KG) | ₹49,811 | Per Ton |
MS H BEAM | 150x150mm(34.5KG) | ₹51,411 | Per Ton |
MS H BEAM | 152x152mm(23KG) | ₹52,011 | Per Ton |
MS H BEAM | 152x152mm(27KG) | ₹51,411 | Per Ton |
MS H BEAM | 152x152mm(31KG) | ₹50,611 | Per Ton |
MS H BEAM | 152x152mm(34KG) | ₹50,611 | Per Ton |
MS H BEAM | 152x152mm(37.1KG) | ₹50,411 | Per Ton |
MS H BEAM | 203x203mm(52KG) | ₹56,011 | Per Ton |
MS H BEAM | 203x152mm(52KG) | ₹51,611 | Per Ton |
Last updated on 25/04/2024 12:38:49 |
Terms & Condition
1. The rates are ex works Raipur, Chattisgarh.
2. GST @ 18% will be charged extra.
3. Loading @ Rs 265/- per mt will be charged extra
4. Transit Insurance will be charged extra @ Rs 40/- per ton.
5. Transportation costs will be charged extra.
6. Payment of 100% advance along with the order. Through bank transfer.
7. Dispatch 1-7 working days from receipt of advance.
8. Material is of commercial grade as per IS 2062.
9. Mill TC can be Provided.
10. Material lengths for trailer and lorry loading would be 11–13 metres and 5.5–6.5 metres, respectively.
11. Depending on the size, amount, and availability of the material, an additional fee of Rs 300 to Rs 500 per metric tonne would be applied to fixed length projects.
12. Actual dispatch quantity may differ +/- 10%.
13. Weight tolerance +/- 0.5% is to be allowed.
14. Rates are subject to minimum order quantity.
15. Rates are subject to change as per the hourly market situation
16. Rates at the time of receipt of advance will be final.
17. Offer is valid till the end of business hours today.
18. Products are subject to availability.
19. Above rates are indicative of market prices. Kindly reconfirm the prices before placing an order.
Item | Size (In mm) | Weight Per Meter In KG | Weight Per Foot in KG | Weight per 12 Meter Pcs (In KG) | Number of Pieces in 1 Metric Ton | Approximate Running Meter Length In 1 (One) Ton |
---|---|---|---|---|---|---|
H Beam | 100x100mm (23KG) | 23.00 | 7.01 | 276.00 | 3.62 | 43.48 |
H Beam | 100x116mm (23KG) | 23.00 | 7.01 | 276.00 | 3.62 | 43.48 |
H Beam | 100x116mm (20KG) | 20.00 | 6.10 | 240.00 | 4.17 | 50.00 |
H Beam | 125x70mm (13.3KG) | 13.30 | 4.05 | 159.60 | 6.27 | 75.19 |
H Beam | 125x70mm (12.0KG) | 12.00 | 3.66 | 144.00 | 6.94 | 83.33 |
H Beam | 125x70mm (11.0KG) | 11.00 | 3.35 | 132.00 | 7.58 | 90.91 |
H Beam | 152x152mm (37.1KG) | 37.10 | 11.31 | 445.20 | 2.25 | 26.95 |
H Beam | 152x152mm (34KG) | 34.00 | 10.36 | 408.00 | 2.45 | 29.41 |
H Beam | 152x152mm (30KG) | 30.00 | 9.14 | 360.00 | 2.78 | 33.33 |
H Beam | 152x152mm (27.0KG) | 27.00 | 8.23 | 324.00 | 3.09 | 37.04 |
H Beam | 175x85mm (16.0KG) | 16.00 | 4.88 | 192.00 | 5.21 | 62.50 |
H Beam | 175x85mm (19.3KG) | 19.30 | 5.88 | 231.60 | 4.32 | 51.81 |
H Beam | 200x200mm (40KG) | 40.00 | 12.19 | 480.00 | 2.08 | 25.00 |
H Beam | 200x200mm (37.31) | 37.31 | 11.37 | 447.72 | 2.23 | 26.80 |
H Beam | 203x152mm (52KG) | 52.00 | 15.85 | 624.00 | 1.60 | 19.23 |
H Beam | 203x203mm (52KG) | 52.00 | 15.85 | 624.00 | 1.60 | 19.23 |
ROLLING TOLERANCES OF STEEL H BEAM | |||
Leg length | Tolerance | Leg length | Camber |
Up to 45 mm | ±1.5 mm | < 100 mm | As per agreement |
> 45 mm to 100 mm | ± 2.0 mm | > 100 mm | 0.2 % of length |
> 100 mm | ± 2 % |  |  |
Â
Tolerance on Sectional | Weight |
Thickness | Tolerance |
Up to 3 mm | ± 5 % |
Over 3 mm | ± 5 %, -3% |
Â
Carbon % | 0.20 |
ManganeseMax % | 0.74 |
SulphurMax % | 0.040 |
PhosporousMax % | 0.024 |
SiliconMax % | 0.20 |
Carbon Equivalent | 0.323 |
Grade Designation | Quality | Tensile Strength Rm Min MPa | Yield | Min | Percentage Elongation A , at Gauge Length , L = 5.65 VS Min | Internal Bend Diameter Min | Charpy Impact Test | ||
 |  |  | < 20 | > 40 |  | < 25 | > 25 | Temp ° ℃ | J , Min |
 | A |  |  |  |  |  |  | - | - |
E - 250 | BR | 410 | 250 | 230 | 23 | 2t | 3t | RT | 27 |
 | BO |  |  |  |  |  |  | 0 | 27 |
Country Of Origin | Made in Bharat (INDIA) | |||
Dispatch Location | Raipur (Chattishgarh) | |||
Material | Mild Steel | |||
Test Certification | Mill TC Available | |||
Shape | H Shape | |||
Size | 100x100mm to 203x203 mm | |||
Minimum Order Quantity (MOQ) | 25 Metric Ton | |||
Packaging Details | Bundles | |||
HSN Code | 72161000, 72163200, 72163300, 72165000, 72163200, 72163200, 72163200 |
Item | Size (In mm) | Weight Per Meter In KG | Weight Per Foot in KG | Weight per 12 Meter Pcs (In KG) | Number of Pieces in 1 Metric Ton | Approximate Running Meter Length In 1 (One) Ton |
H Beam | 100x100mm (23KG) | 23.00 | 7.01 | 276.00 | 3.62 | 43.48 |
H Beam | 100x116mm (23KG) | 23.00 | 7.01 | 276.00 | 3.62 | 43.48 |
H Beam | 100x116mm (20KG) | 20.00 | 6.10 | 240.00 | 4.17 | 50.00 |
H Beam | 125x70mm (13.3KG) | 13.30 | 4.05 | 159.60 | 6.27 | 75.19 |
H Beam | 125x70mm (12.0KG) | 12.00 | 3.66 | 144.00 | 6.94 | 83.33 |
H Beam | 125x70mm (11.0KG) | 11.00 | 3.35 | 132.00 | 7.58 | 90.91 |
H Beam | 152x152mm (37.1KG) | 37.10 | 11.31 | 445.20 | 2.25 | 26.95 |
H Beam | 152x152mm (34KG) | 34.00 | 10.36 | 408.00 | 2.45 | 29.41 |
H Beam | 152x152mm (30KG) | 30.00 | 9.14 | 360.00 | 2.78 | 33.33 |
H Beam | 152x152mm (27.0KG) | 27.00 | 8.23 | 324.00 | 3.09 | 37.04 |
H Beam | 175x85mm (16.0KG) | 16.00 | 4.88 | 192.00 | 5.21 | 62.50 |
H Beam | 175x85mm (19.3KG) | 19.30 | 5.88 | 231.60 | 4.32 | 51.81 |
H Beam | 200x200mm (40KG) | 40.00 | 12.19 | 480.00 | 2.08 | 25.00 |
H Beam | 200x200mm (37.31) | 37.31 | 11.37 | 447.72 | 2.23 | 26.80 |
H Beam | 203x152mm (52KG) | 52.00 | 15.85 | 624.00 | 1.60 | 19.23 |
H Beam | 203x203mm (52KG) | 52.00 | 15.85 | 624.00 | 1.60 | 19.23 |
ROLLING TOLERANCES OF STEEL H BEAM | |||
Leg length | Tolerance | Leg length | Camber |
Up to 45 mm | ±1.5 mm | < 100 mm | As per agreement |
> 45 mm to 100 mm | ± 2.0 mm | > 100 mm | 0.2 % of length |
> 100 mm | ± 2 % |  |  |
Tolerance on Sectional | Weight |
Thickness | Tolerance |
Up to 3 mm | ± 5 % |
Over 3 mm | ± 5 %, -3% |
Carbon % | ManganeseMax % | SulphurMax % | PhosporousMax % | SiliconMax % | Carbon Equivalent |
 |  |  |  |  |  |
0.20 | 0.74 | 0.040 | 0.024 | 0.20 | 0.323 |
Grade Designation | Quality | Tensile Strength Rm Min MPa | Yield | Min | Percentage Elongation A , at Gauge Length , L = 5.65 VS Min | Internal Bend Diameter Min | Charpy Impact Test | ||
 |  |  | < 20 | > 40 |  | < 25 | > 25 | Temp ° ℃ | J , Min |
 | A |  |  |  |  |  |  | - | - |
E - 250 | BR | 410 | 250 | 230 | 23 | 2t | 3t | RT | 27 |
 | BO |  |  |  |  |  |  | 0 | 27 |
Country Of Origin | Made in Bharat (INDIA) | |||
Dispatch Location | Raipur (Chattishgarh) | |||
Material | Mild Steel | |||
Test Certification | Mill TC Available | |||
Shape | H Shape | |||
Size | 100x100mm to 203x203 mm | |||
Minimum Order Quantity (MOQ) | 25 Metric Ton | |||
Packaging Details | Bundles | |||
HSN Code | 72161000, 72163200, 72163300, 72165000, 72163200, 72163200, 72163200 |
