MS Beam (Raipur)

I Beams, Steel Beams and Iron Beam all are metal section elements renowned for their strength and durability. Their distinctive shape, resembling the letter “I” allows them to bear heavy loads and provide structural support. These beams have a high strength-to-weight ratio which makes them ideal for constructing buildings, bridges and other large structures.

We at Shree Ji Steel Private Limited (formerly Shree Ji Steel Corporation) offers essential component for construction and engineering projects including I Beams. These Iron Beams are widely used for the construction of flyovers, pedestrian walkovers, factory sheds, conveyors and boilers. The beams are available in various sizes, weights and load-bearing capacities, ensuring versatility and adaptability for diverse applications. The company adheres to strict quality norms, resulting in superior I Beams that meet structural integrity and safety requirements.

Shree Ji Steel Corporation ensures a steady supply of construction projects in the region. Contractors, architects and engineers all rely on these beams for their structural needs. The diverse range of iron beams meets the specific requirements of various applications. With a focus on quality and precision, Shree Ji Steel Private Limited continues to contribute to the development of the steel and construction industries both locally and globally.

STEEL I BEAM PRICE CHART

ITEAM NAMESIZEPRICEUNIT
MS BEAM100x50mm₹49,111Per Ton
MS BEAM100x60mm₹49,611Per Ton
MS BEAM120x70mm₹49,911Per Ton
MS BEAM125x70mm₹48,811Per Ton
MS BEAM125x75mm₹48,811Per Ton
MS BEAM150x75mm₹48,811Per Ton
MS BEAM175x85mm₹51,311Per Ton
MS BEAM200x100mm₹49,511Per Ton
MS BEAM250x125mm₹50,111Per Ton
MS BEAM300x140mm₹51,011Per Ton
MS BEAM350x140mm₹52,511Per Ton
MS BEAM400x140mm₹52,011Per Ton
MS BEAM450x150mm₹53,511Per Ton
MS BEAM500x180mm₹55,011Per Ton
MS BEAM600x210mm₹58,011Per Ton
Last updated on 25/04/2024 12:38:49

Terms & Condition
1. The rates are ex works Raipur, Chattisgarh.
2. GST @ 18% will be charged extra.
3. Loading @ Rs 265/- per mt will be charged extra
4. Transit Insurance will be charged extra @ Rs 40/- per ton.
5. Transportation costs will be charged extra.
6. Payment of 100% advance along with the order. Through bank transfer.
7. Dispatch 1-7 working days from receipt of advance.
8. Material is of commercial grade as per IS 2062.
9. Mill TC can be Provided.
10. Material lengths for trailer and lorry loading would be 11–13 metres and 5.5–6.5 metres, respectively.
11. Depending on the size, amount, and availability of the material, an additional fee of Rs 300 to Rs 500 per metric tonne would be applied to fixed length projects.
12. Actual dispatch quantity may differ +/- 10%.
13. Weight tolerance +/- 0.5% is to be allowed.
14. Rates are subject to minimum order quantity.
15. Rates are subject to change as per the hourly market situation
16. Rates at the time of receipt of advance will be final.
17. Offer is valid till the end of business hours today.
18. Products are subject to availability.
19. Above rates are indicative of market prices. Kindly reconfirm the prices before placing an order.

Price Chart History

Additional Information

I BEAM WEIGHT CHART

ItemSize (In mm)Weight Per Meter In KG Weight Per Foot in KGWeight per 12 Meter Pcs (In KG)Number of Pieces in 1 Metric TonApproximate Running Meter Length In 1 (One) Ton
I Beams100x50x4.7mm8.952.731079112
I Beams125mm (Light)11.873.62142784
I Beams125x70x5mm13.354.07160675
I Beams150x75x5mm14.964.56180667
I Beams175mm (Light)16.595.06199560
I Beams175x85x5.8mm19.505.94234451
I Beams200x100x5.7mm24.177.37290341
I Beams250x125x6.9mm37.3011.37448227
I Beams300x140x7.7mm46.0214.03552222
I Beams350x140x8.1mm52.3315.95628219
I Beams400x140x8.9mm61.5518.76739116
I Beams450x150x9.4mm72.3822.06869114
I Beams500x180x10.2mm86.8826.481043112
I Beams600x210x12mm121.0036.88145218

I BEAM CHEMICAL COMPOSITION: (IN % MAXVALUES)
Carbon %0.20
ManganeseMax %0.89
SulphurMax %0.035
PhosporousMax %0.041
SiliconMax %0.24
Carbon Equivalent0.37
I BEAM MECHANICAL COMPOSITION: (IN % MAXVALUES)
Tensile Strength Min, Mpa340.45
Yield Stress, Min, MPa525.36
% Elongation atgauge length5.65 √Ѕo31.8
Bend TestOK
ADDITIONAL INFORMATION OF I BEAM
Country Of OriginMade in Bharat (INDIA)
Dispatch LocationRaipur (Chattishgarh)
MaterialMild Steel
Test CertificationISI Test Certificate & Mill TC Available
ShapeꞮ Shape
Size100x50mm to 600x210mm
Minimum Order Quantity (MOQ)25 Metric Ton
Packaging DetailsBundles
HSN Code72161000, 72163200, 72163300, 72165000, 72163200, 72163200, 72163200

Additional Information

ItemSize (In mm)Weight Per Meter In KGWeight Per Foot in KGWeight per 12 Meter Pcs (In KG)Number of Pieces in 1 Metric TonApproximate Running Meter Length In 1 (One) Ton
I Beams100x50x4.7mm8.952.731079112
I Beams125mm (Light)11.873.62142784
I Beams125x70x5mm13.354.07160675
I Beams150x75x5mm14.964.56180667
I Beams175mm (Light)16.595.06199560
I Beams175x85x5.8mm19.505.94234451
I Beams200x100x5.7mm24.177.37290341
I Beams250x125x6.9mm37.3011.37448227
I Beams300x140x7.7mm46.0214.03552222
I Beams350x140x8.1mm52.3315.95628219
I Beams400x140x8.9mm61.5518.76739116
I Beams450x150x9.4mm72.3822.06869114
I Beams500x180x10.2mm86.8826.481043112
I Beams600x210x12mm121.0036.88145218
