Shree Ji Steel Private Limited (formerly Shree Ji Steel Corporation) owns the distribution and sales rights of Lightweight TMT Bar. These bars are unique in their properties. They are much lighter in weight than general TMT Bars. They are made of mild steel. They are used as important construction materials. These Underweight TMT Bars are the best option for construction projects. They also reduce the overall weight of the structure, which is the most important factor in earthquake-prone areas.Â
Lightweight TMT Bar has a better strength-to-weight ratio than conventional TMT. These are more economical and environmentally friendly. It is also easier to handle because it can be cut and twisted without losing its toughness or durability. Underweight TMT Bars that we provide at Shree Ji Steel Private Limited, are the most flexible, corrosion-resistant and strong enough to be the structural base of the construction.Â
Shree Ji Steel Private Limited offers a variety of Lightweight TMT Bars to meet the requirements of different construction projects. These Underweight TMT Bars are manufactured with advanced equipment and high-quality materials, which ensures their robustness, longevity and durability. Shree Ji Steel Corporation is a recognized dealer and supplier of LightWeight TMT. The company offers high-quality products that meet the specific requirements of construction projects. Due to its strength, durability and ease of use, the Lightweight TMT Bar is an excellent choice for any construction project where weight is to be reduced, efficiency is increased and money is saved.
| Diameter in mm | TMT Bar Length In Meters | Weight Per Meter In KG | Weight Per Foot in KG | Weight Per 12 Meter Pcs (weight In KG) | Number of Pieces in 1 Metric Ton | Approximate Running Meter Length In 1 (One) Ton |
|---|---|---|---|---|---|---|
| Lightweight TMT Bar 8mm | 12 meter | 0.347 | 0.11 | 4.164 | 240 | 2882 |
| Lightweight TMT Bar 10mm | 12 meter | 0.520 | 0.16 | 6.24 | 160 | 1923 |
| Lightweight TMT Bar 12mm | 12 meter | 0.833 | 0.25 | 9.996 | 100 | 1200 |
| Lightweight TMT Bar 16mm | 12 meter | 1.416 | 0.43 | 16.992 | 59 | 706 |
| Carbon (%) | 0.18-0.19 |
| Sulphur (%) | 0.026-0.028 |
| Phosphorus (%) | 0.031-0.032 |
| Sulphur & Phosphorus (%) | 0.055-0.057 |
| %C.E | 0.28-0.30 |
| Nitrogen Content | 0.007 |
| 0.2% Proof Stress /YSN/mm2 (min) | 530 |
| 0.2% Proof Stress /YSN/mm2 (max) | 550 |
| Tensile Strength (N/mm2) | 635 |
| TS/YS Ratio | 1.19 |
| Elongation (%) | 22 |
| Total Elongation at max force (%) | 8.2 |
| Bend Test | ok |
| Re-bend Test | Pass |
| Country Of Origin | Made in Bharat (INDIA) | |||
| Dispatch Location | Durgapur (West Bengal) | |||
| Material | Mild Steel | |||
| Test Certification | Mill TC Available | |||
| Shape | Ribbed Bar | |||
| Size | 4.5 mm -16mm | |||
| Minimum Order Quantity (MOQ) | 25 Metric Ton | |||
| Packaging Details | Bundles | |||
| HSN Code | 72131090, 72141090, 72142090, 721499, 72149990, 72141090, 72151000 | |||
| ITEAM NAME | SIZE | PRICE | UNIT |
|---|---|---|---|
| LIGHTWEIGHT TMT BAR | 8mm | ₹52,764 | Per Ton |
| LIGHTWEIGHT TMT BAR | 10mm | ₹50,994 | Per Ton |
| LIGHTWEIGHT TMT BAR | 12mm | ₹50,994 | Per Ton |
| LIGHTWEIGHT TMT BAR | 16mm | ₹50,994 | Per Ton |
| Last updated on 05/11/2024 20:39:11 |
Terms and Conditions :
1. The rates are ex works Kolkata, Durgapur, West Bengal, India.
2. All Rate are including 18% GST.
3. All Rate are including Loading Charges.
4. All Rate are including Transit Insurance Charges.
5. Transportation cost will be charged extra.
6. Payment 100% advance along with the order through Bank Transfer
7. Dispatch 1-7 working days from receipt of advance.
8. GRADE: FE500/FE500D/FE550D/FE600 TMT Bar available
9. Length of the material would be 12 meters.
10. Actual dispatch quantity may differ +/- 10%.
11. Weight tolerance +/- 0.5% is to be allowed.
12. Rates are subjected to minimum order quantity.
13. Rates are subject to change as per hourly market situation. Rates at the time of receipt of advance will be final.
14. Unloading at client’s scope.
15. Products are subject to availability.
16. Above rates are indicative market prices. Kindly reconfirm the prices before placing an order.
We have lightweight TMT bars of secondary brands. Please connect with the sales team of Shree Ji Steel Pvt. Ltd. for more details.Â
Lightweight TMT bars are designed to be lighter and easier to handle while offering utmost strength compared to normal TMT bars. They are often used in applications where reducing weight is crucial. Normal TMT bars provide standard strength and durability and are widely used in conventional construction projects.
The weight of One Bundle Lightweight TMT can be different based on the diameter of the TMTs. The lightweight TMTs with diameter of 08MM, 10MM and 12MM can be of 46-50 Kgs in a bundle. However, the lightweight TMT with a diameter of 16mm can be 48-52 kgs in a bundle.
We offer varieties of lightweight TMT bars from secondary manufacturers. For precise information, it's best to consult with our sales team.
If your order matches our criteria and the minimum order quantity, we can deliver your order. But the delivery of the order depends on the type of order you placed and the quantity requirements.   Â
Rates available on the Websites are promptly updated as per the market rates. It is applicable for all customers, no matter whether it is a dealer or shopkeeper. Please consult with the sales team for further details. The date of the last update is always mentioned under the rate chart, please refer to that. Â
Lightweight TMT bars are available in several grades, including Fe 500, Fe 500D, Fe 550, Fe 550D and Fe 600. Each grade is designed to meet specific strength and durability requirements for construction projects. For precise information on available grades, it's best to consult with our sales team at https://wa.me/917044459444.Â
The applicable GST rate on our products is 18%. Â
No, Magnet rod TMT is not available at Shree Ji Steel Corporation.Â
