What Are the Technical Specifications of the Cold Dip GI L Angle Used in Scaffolding Projects?

IN THIS ARTICLE

The Cold Dip GI L Angle is a structural item that finds extensive application in scaffolding and construction work that demands high strength, durability, and corrosion resistance. GI L Angles are not manufactured from zinc that meets IS standards, providing long-lasting performance even in demanding site conditions. The coating is a zinc coating applied by cold dip to achieve a uniform protective layer with known coating thickness and weight. All GI L Angle consists of rigorous quality testing, including measurement of coating thickness and mechanical performance, to ensure it can be used. As Indian Standards-compliant, both zinc- and steel-coated, the Cold Dip GI L Angles are a reliable product for projects that demand certified structural material tested and ready for approval.

What Is the Minimum Order Quantity and the Supply Condition for Cold-Dip GI L Angle?

The minimum quantity of Cold Dip GI L Angle to be purchased is 25 tons. This amount is required across the board for bulk supply orders. Customers are also given leeway in their logistics arrangements. Transportation insurance may be waived at the buyer’s request if necessary. This gives procurement teams better control over cost and transit-related decisions, as the certified GI L Angle materials are sourced for scaffolding and structural use.

What Grade of Zinc and Steel Is Used in Cold Dip GI L Angle?

The cold Dip GI L Angle is produced with zinc in accordance with IS 209:1985. The level of zinc employed in the galvanizing process is 99.995%, providing very high corrosion resistance and consistent coating.

The core material used is MS Angle, which is compliant with IS 2633:1985. This type of steel is often used in structural work and is suitable for applications requiring certified, standardized materials. The application of the mentioned grades ensures that the Cold Dip GI L Angle is appropriate for a project that requires adherence to the accepted Indian Standards.

What Are the Coating Thickness and Test Results of the Cold Dip GI L Angle?

Durable and perform well in terms of mechanical performance. The thickness of the zinc layer, as measured by the electrometer, is 90 micrometers or more, indicating a firm, protective galvanizing layer.

The final result of the coating test is documented at 711.59 g/m2, and hence, sufficient zinc has been deposited according to testing standards.

Besides coating evaluation, GI L Angle has also passed the pivot hammer test, with no peel-off. These findings indicate that the product is resistant to handling, installation, and service stresses during scaffolding processes.

What Are the Standard Length and Weight Parameters of the GI / MS L Angle?

Normal MS and GI L Angle length of supply also differ according to the type of supply. The half-length angles have lengths between 5.5 meters and 6.5 meters. The lengths provided are full-length angles of 11 meters and 13 meters.

The weight of one MS Angle is not fixed and varies with the size of the angle section. The MS Angle weight chart from the supplier provides weight information for various sizes. This will enable buyers to properly assess the material requirements and loading issues of scaffolding structures.

Conclusion

Cold Dip GI L Angle offers a high-quality balance of strength, corrosion resistance, and compliance with Indian Standards. Having high-purity zinc coating, tested coating thickness, passed mechanical tests, and standardized steel grades, it can be used in scaffolding and structural applications. Different lengths and the clarity of the weight parameters also assist in efficient project planning.

For engineers and procurement teams evaluating different structural options, it’s also useful to understand the differences between custom and standard L Angles—as discussed in this blog on Custom vs. Standard L Angles: Which One Should Engineers Choose?  to decide the most suitable type of L Angle for specific project requirements.

FAQs

What is the minimum order quantity for Cold Dip GI L Angle?

The minimum purchase quantity for Cold Dip GI L Angle is fixed at 25 tons, making it suitable for bulk procurement in large scaffolding and infrastructure projects.

Which zinc standard is used for galvanizing Cold Dip GI L Angle?

Cold Dip GI L Angle is galvanized using zinc conforming to IS 209:1985 standards, with a high purity level of 99.995 percent.

What is the coating thickness of Cold Dip GI L Angle?

The zinc coating thickness of Cold Dip GI L Angle is measured using an electrometer and consistently records 90 microns or above.

Has the Cold Dip GI L Angle passed mechanical testing?

Yes, Cold Dip GI L Angle has been tested regarding the pivot hammer test, and there has been no peel-off or damage to the galvanized coating.

Does the weight of the GI L Angle remain the same for all sizes?

No, the minimum weight of the GI or MS L Angle varies with the angle size, and the supplier provides detailed weight charts.
