To meet the demands of construction and metal fabrication, it is important to seek structural components that ensure strength and long-term performance. It is the time when high-quality MS Channel stands out. A trusted Supplier can supply a diverse range of options depending on requirements. Experts may recommend using Mild Steel C Channel at times, as it is known for its dimensional accuracy and load-bearing capabilities.
Whether constructing a factory shed, a warehouse frame, or a structural support beam, considering the available sizes may help make the right decision. It enhances structural stability and optimises material efficiency.
Why MS Channel Size Matters for Steel Framing?
MS C Chanel size gives an idea of whether it can handle the load. In addition, it is necessary to resist bending to maintain the shape in some projects. Channel dimensions such as 70X35mm, 100X50mm, 200X75mm, and 250X80mm may provide load-bearing strength. From a larger channel, it becomes possible to get extensive support. However, it may add some weight and cost.
| ITEM NAME | SIZE |
|---|---|
| MS CHANNEL | 70x35mm (3.8 Kg/Mtr Super Lite) |
| MS CHANNEL | 75x40mm (5 Kg/Mtr Lite) |
| MS CHANNEL | 75x40mm (5.5 Kg/Mtr Medium) |
| MS CHANNEL | 75x40mm (7.14 Kg/Mtr Heavy) |
| MS CHANNEL | 95x45mm (5.8 Kg/Mtr Super Lite) |
| MS CHANNEL | 100x50mm (8 Kg/Mtr Lite) |
| MS CHANNEL | 100x50mm (8.5 Kg/Mtr Medium) |
| MS CHANNEL | 100x50mm (9.56 Kg/Mtr Heavy) |
| MS CHANNEL | 125x65mm (13.5KG) |
| MS CHANNEL | 125x65mm (10.5KG) Lite |
| MS CHANNEL | 125x70mm |
| MS CHANNEL | 150x75mm |
| MS CHANNEL | 175x75mm |
| MS CHANNEL | 200x75mm (22KG) |
| MS CHANNEL | 200x75mm (18.5KG) Lite |
| MS CHANNEL | 225mm |
| MS CHANNEL | 250x80mm (Lite) |
| MS CHANNEL | 250x82mm |
| MS CHANNEL | 300x90mm |
| MS CHANNEL | 400x100mm |
For example, 70X35X3.8mm, which weighs around 4.20kg/m, is the best option for light-framing partitions. However, it can also be used for small fabrication projects. On the other hand, a 100x55X5mm usually weighs 9.56kg/m. It can work well for medium-duty structural tasks. If it is a 200X75X6.2mm MS C Channel, it weighs 22.30 kg/m, making it ideal for industrial-scale structures. When the channel size is very large, about 400X100X8.8mm, it may weigh about 50.10kg/m. They can be used in high-load applications, such as long-span beams and equipment platforms. With expert assistance, the right size for the application can be chosen. It may be possible to achieve the optimal size without adding unnecessary weight.
| C CHANNEL WEIGHT CHART | ||||||
|---|---|---|---|---|---|---|
| Size (in mm) | Specification | Weight (in kg/meter) | Weight (in kg/feet) | WEIGHT PER 12 METER PCS | APPROXIMATE PIECES IN TON (SINGLE PIECE LENGTH 12 METER) | APPROXIMATE RUNNING METER LENGTH IN (ONE TON) |
| 70×35 channel weight | 70X35X3.8 mm | 4.20 | 1.28 | 50 | 19.84 | 238.10 |
| 75×40 channel weight | 75X40X3.7 mm (Light) | 5.70 | 1.74 | 68 | 14.62 | 175.44 |
| 75×40 channel weight | 75X40X4.8 mm (MEDIUM) | 2.1 | 0.64 | 25 | 39.68 | 476.19 |
| 75×40 channel weight | 75X40 mm (HEAVY) | 7.1 | 2.16 | 85 | 11.74 | 140.85 |
| 95×45 channel weight | 95X45 mm | 6.00 | 1.83 | 72 | 13.89 | 166.67 |
| 100×50 channel weight | 100X45X3 mm (Light) | 5.8 | 1.77 | 70 | 14.37 | 172.41 |
| 100×50 channel weight | 100X50X4 mm (Medium) | 7.9 | 2.41 | 95 | 10.55 | 126.58 |
| 100×50 channel weight | 100X50X5 mm (HEAVY) | 9.56 | 2.91 | 115 | 8.72 | 104.60 |
| 125×65 channel weight | 125X65X5.3 mm | 13.10 | 3.99 | 157 | 6.36 | 76.34 |
| 125×50 channel weight | 125X50X3 mm | 10.00 | 3.05 | 120 | 8.33 | 100.00 |
| 150×75 channel weight | 150X75X5.7 mm | 16.80 | 5.12 | 202 | 4.96 | 59.52 |
| 175×75 channel weight | 175X75X6 mm | 19.60 | 5.97 | 235 | 4.25 | 51.02 |
| 200×75 channel weight | 200X75X6.2 mm | 22.30 | 6.80 | 268 | 3.74 | 44.84 |
| 250×80 channel weight | 250X80X7.2 mm | 34.20 | 10.42 | 410 | 2.44 | 29.24 |
| 250×82 channel weight | 250X82X9 mm | 30.60 | 9.33 | 367 | 2.72 | 32.68 |
| 300×90 channel weight | 300X90X7.8 mm | 36.30 | 11.06 | 436 | 2.30 | 27.55 |
| 350×100 channel weight | 350X100X8.3 | 42.70 | 13.01 | 512 | 1.95 | 23.42 |
| 400×100 channel weight | 400X100X8.8 mm | 50.10 | 15.27 | 601 | 1.66 | 19.96 |
What Are the Best MS Channel Sizes for Different Steel Framing Needs?
Based on the project type, experts may determine the MS Channel size. For light-duty projects, such as small trusses, sheds, or light partitions, it may be essential to make a practical and efficient choice. It is better to use options such as 70X25mm, 75X40mm, and 95X45mm Lite. From this type of MS Channel, it is possible to enjoy sufficient rigidity while staying economical.
For the medium-duty structure, such as mid-sized frames and roofing, it becomes necessary to utilise moderate strength. 100X55mm channels are available in a range of thicknesses, making them a perfect choice for different applications. It may ensure both the cost-efficiency and load-bearing capacity. If it is a 125X65mm, it may be suited for the project where additional stability is required.
Load demands are especially high in heavy-duty industrial framing. On occasion, a large channel can offer necessary support. Whether it is an MS Channel of 150X75mm, 175X75mm, 200X75mm, or 400X100mm, they can guarantee rigidity, reduce deflections, and maintain structural integrity even under demanding conditions.
Which MS Chanel Size Ensures the Best Efficiency?
Load requirement plays an important role in maintaining efficiency. Here, it may be necessary to use the smallest possible section. It must meet the structural requirements to ensure a safe environment.
For general steel framing applications, it is better to utilise an MS Channel size of 100 x 50 mm. It can be either medium- or heavy-thick. It is certainly one of the most balanced options to find. It usually ensures dependable strength, good availability, manageable weight and ease of fabrication. For large industrial applications, experts recommend utilising 150X75mm and 200X75mm MS Channel. If it is a smaller structure that requires ease of handling and cost-efficiency, it is better to install a lightweight size, such as 75X40mm.
Shree Ji Steel Private Limited offers a wide range of MS Channels sourced from Raipur. Contact us today for high-quality material.
FAQs
What are the Best MS Channel Size for Small Building Frames?
Smaller structures need efficient options such as 70X35mm, 75X40mm, and 95X45mm. These options allow you to achieve adequate strength while keeping weight low.
How to Differentiate Between Light, Medium and Heavy MS Channel?
Decisions can be made solely based on the load requirements. Light channels may be used for a rack or partitions. If it is a medium channel, it can be a perfect option for the general framing. On the other hand, heavy channels can be ideal for long spans and industrial structures.
Is it Better to Use Heavy C Channels for Safety?
Not always. Heavy channel comes at a higher cost. In addition, it may add weight without improving efficiency. Therefore, it is better to use this option when a higher load-bearing capacity is required. By choosing the smallest MS channels, it is possible to maintain the safety standards effectively.
