SAIL WPB

Wide Flange Parallel Beam (WPB) is an important high-strength structural steel component. It is widely used in modern construction and engineering applications. It is designed with parallel flange surfaces to ensure superior load-bearing capacity with efficient weight distribution. At Shree Ji Steel Private Limited, we provide high-quality wide flange beams that meet global standards, ensuring superior structural integrity for all your projects. WPB beams provide a uniform thickness across the flange that makes Wide Flange Parallel Beam easy to fabricate and weld in construction projects. SAIL WPB beams are manufactured using high-quality steel, to deliver excellent strength and durability. The Wide Flange Beam of SAIL complies with international structural standards and the European H beam benchmark. SAIL WPB beams are also alternatively known as SAIL H Beam, as the Wide parallel flange forms H Shape.

One key advantage of Wide-Flange Parallel Beams (WPBs) is their ability to support heavy loads with much greater stability. SAIL WPB flange design has better weight distribution to reduce stress concentration on the Product of Steel. It is enhancing the overall strength of the structure. It makes SAIL WPB beams an ideal choice for applications in bridges, and industrial plants. It is also used in high-rise buildings, and warehouses for better structural integrity.

SAIL WPB Beams are also preferred for their efficiency in material usage. Compared to traditional beams, Parallel Flange Beams & Columns minimize steel wastage while maximizing load-bearing efficiency. It makes the SAIL WPB beam a cost-effective solution in large-scale construction projects. These are also widely recognized in the industry for the precision engineering of the Steel Authority of India. As a product of the Steel Authority of India Limited, these WPB beams are essential for modern infrastructure development. It ensures safety and reliability in various structural applications.

SAIL WPB beams are designed for enhanced durability and efficiency. Their parallel flange beams & columns provide excellent stability. It also ensures uniform load distribution across various applications. These beams are extensively used in bridges and infrastructure engineering. Hence, SAIL WPB is considered one of the most trusted solutions in the industry for its consistent quality and performance. The precision engineering behind SAIL H beams ensures optimal strength and reliability, making them a preferred choice for architects and engineers.

Additional Information

SAIL ISMB WEIGHT CHART

Search:

Item	Size (In mm)	Weight Per Meter In KG	Weight Per Foot in KG	Weight per 12 Meter Pcs (In KG)	Number of Pieces in 1 Metric Ton	Approximate Running Meter Length In 1 (One) Ton
SAIL BEAM	125x70x5mm	13.35	4.07	160	6.24	74.91
SAIL BEAM	150x75x5.0mm	14.96	4.56	180	5.57	66.84
SAIL BEAM	200x100x5.7mm	25.4	7.74	305	3.28	39.37
SAIL BEAM	250x125x6.9mm	37.3	11.37	448	2.23	26.81
SAIL BEAM	300x140x7.7mm	46.1	14.05	553	1.81	21.69
SAIL BEAM	350x140x8.1mm	52.4	15.97	629	1.59	19.08
SAIL BEAM	400x140x8.9mm	61.6	18.78	739	1.35	16.23
SAIL BEAM	450x150x9.4mm	72.4	22.07	869	1.15	13.81
SAIL BEAM	500x180x10.2mm	86.9	26.49	1043	0.96	11.51
SAIL BEAM	600x210x12mm	123	37.49	1476	0.68	8.13

ROLLING TOLERANCES OF SAIL BEAM
Leg length	Tolerance	Leg length	Camber
Up to 45 mm	±1.5 mm	< 100 mm	As per agreement
> 45 mm to 100 mm	± 2.0 mm	> 100 mm	0.2 % of length
> 100 mm	± 2 %

Tolerance on Sectional	Weight
Thickness	Tolerance
Up to 3 mm	± 5 %
Over 3 mm	± 5 %, -3%

SAIL BEAM CHEMICAL COMPOSITION: (IN % MAXVALUES)

Carbon %	ManganeseMax %	SulphurMax %	PhosporousMax %	SiliconMax %	Carbon Equivalent

0.20	0.74	0.040	0.024	0.20	0.323

SAIL BEAM MECHANICAL PROPERTIES: (IN % MAXVALUES)

Grade Designation	Quality	Tensile Strength Rm Min MPa	Yield	Min	Percentage Elongation A , at Gauge Length , L = 5.65 VS Min		Internal Bend Diameter Min	Charpy Impact Test
			< 20	> 40		< 25	> 25	Temp ° ℃	J , Min
	A							-	-
E - 250	BR	410	250	230	23	2t	3t	RT	27
	BO							0	27

Sample Test Certificate of SAIL BEAM

SAIL ISMB ADDITIONAL INFORMATION

Country Of Origin	Made in Bharat (INDIA)
Dispatch Location	Durgapur (West Bengal) , Raipur (Chattishgarh)
Material	Mild Steel
Test Certification	SAIL ( Steel Authority of India )Test Certificate
Shape	Ɪ Shape
Minimum Order Quantity (MOQ)	25 Metric Ton
Packaging Details	Bundles
HSN Code	72161000, 72163200, 72163300, 72165000, 72163200, 72163200, 72163200

Frequently Asked Questions (FAQs) on SAIL ISMB

Will it be used in the MES and Railway projects ?

SAIL or Steel authority of Indian limited is one of the leading primary brand of steel products in India. All the products of the SAIL are entitled to pass all the tests imposed on Steel products before their use in any project. Thus, it can be stated that, SAIL TMT can be used in the MES and Railway priojects.

What is the Minimum order quantity of the SAIL beam?

The minimum order quantity of SAIL beam is 25 tons.

Can I get both standard and customised beam sizes from SAIL?

No, customised beams can not be aviled from Shree ji Steel. At the same time, all the beams sourced from SAIL are of standard length.

Does SAIL has different types of beams such as I-beams, H-beams, or Universal beams?

Yes, SAIL has different conbinatins of beams, such as I beams, H Beams, UC Beams.

What is the grade of the SAIL beam?

The grade of the available SAIL beam at Shree Ji Steel are of IS 2062 E 250 grade.

Are SAIL beams suitable for high-rise construction or heavy industrial applications?

Yes, SAIL bemas are suitable for the high rise construction s and heavy industrial operations.

Are there any extra costs involved, such as taxes or handling fees after placing the order with token money ?

All the costs are mentioned in terms and conditions. Generally loading charge, GST and insurance for transportation are charged extra.

Can I track my order once the beams have been dispatched?

Yes, after you place the order with us, you would be notified in every stages status of delivery. Starting from the loading process to the delivery at your location, you would be connected to our customer care team. You would also be updated about your shipment status, through our customer care WhatsApp Group.

Are the beams can be transported in a Surface transportation services.

The mode of transport utlised by Shree Ji Steel private limited is usually surface transport services. However, in case of special need, the alternate method of transportation can be opted. Still, all the materials are transported mostly using the surface transportation process.

Can I order customised beams from SAIL based on specific project dimensions?

No, you can not place order SAIL with customisation of the beams.

Can I place an order for SAIL beams with mixed dimensions or grades?

Yes, you can place an order for SAIL beams with mixed dimensions.

Can I place the mix order of NPB and H beam ?

Yes, you can place an order for the NPB and H Beam in a signle order.

Additional Information

SAIL WPB BEAM WEIGHT CHART

If you are Looking for the latest SAIL WPB Weight Chart, Visit our website. This the updated SAIL WPB weight chart with detailed and precise weights for various sizes is important to make purchasing decission. At Shree Ji Steel Private Limited, we ensure accurate data to help you make informed decisions. Your trusted source for precise and reliable information.

Item	European Beam Standard	Size (in mm)	Weight Per Meter In KG	Weight Per Foot in KG	Weight Per 12 Meter Pcs	Number of Pieces in 1 Metric Ton	Approximate Running Meter Length In 1 (One) Ton
WPB 160	HE 160 AA	160x160mm	22.75	6.93	273	3.66	43.96
WPB 160	HE 160 A	160x160mm	30.44	9.28	365	2.74	32.85
WPB 160	HE 160 B	160x160mm	42.59	12.98	511	1.96	23.48
WPB 160	HE 160 M	160x160mm	76.19	23.22	914	1.09	13.13
WPB 200	Standard	200x200mm	37.34	11.38	448	2.23	26.78
WPB 200	HE 200 AA	200x200mm	34.65	10.56	416	2.41	28.86
WPB 200	HE 200 A	200x200mm	42.26	12.88	507	1.97	23.66
WPB 200	HE 200 B	200x200mm	61.30	18.68	736	1.36	16.31
WPB 240	HE 240 AA	240x240mm	47.40	14.45	569	1.76	21.10
WPB 240	HE 240 A	240x240mm	60.32	18.39	724	1.38	16.58
WPB 240	HE 240 B	240x240mm	83.20	25.36	998	1.00	12.02
WPB 240	HE 240 M	240x240mm	156.68	47.76	1880	0.53	6.38
WPB 300	HE 300 AA	300x300mm	100.85	30.74	1210	0.83	9.92
WPB 300	HE 300 B	300x300mm	117.03	35.67	1404	0.71	8.54
WPB 300	HE 300 M	300x300mm	237.92	72.52	2855	0.35	4.20

SAIL WPB CHEMICAL COMPOSITION: (IN % MAXVALUES)

Chemical composition refers to the precise arrangement and proportion of elements within a material. It is used to define the properties and performance of SAIL WPB. Understanding the chemical properties of Iron SAIL H Beam is crucial for understanding the safety, durability of construction project. Check the chemical properties of SAIL WPB supplied by Shree Ji Steel.

Sizes	Carbon (%)	Manganese	Sulphur (%)	Phosphorus (%)	%C.E
8mm	0.15	0.61	0.031	0.035	0.25
10mm	0.14	0.56	0.032	0.035	0.23
12mm	0.15	0.63	0.031	0.038	0.26
16mm	0.13	0.57	0.031	0.038	0.23
20mm	0.14	0.61	0.032	0.035	0.24

SECTIONAL PROPERTIES OF SAIL WPB

Sectional Properties of SAIL WPB shows the strength, flexibility of the materials of SAIL H Beam. The durability for construction is also highlighted by the mechanical properties of SAIL WPB. The Key mechanical properties include yield and tensile strength, elongation, bendability for shaping.

Sectional Properties of a SAIL WPB

WFB	Mass	Area (A)	Distance of Two Flage (D)	Width of Flange (B)	Web / Joining Part Thickness (t)	Flange Thickess (T)	FIangeSIope(α)	Root Radius (R1)
WFB	M (Kg/M)	mm2	mm	mm	mm	mm	degrees	mm
WPB 160x160 x 22.75	22.75	28.9	148	160	4.5	7.0	90.0	8.0
WPB 160x 160 x 30.44	30.44	38.7	152	160	6.0	9.0	90.0	15.0
WPB 160x160 x 42.59	42.59	54.2	160	160	8.0	13.0	90.0	15.0
WPB 160 x160 x 76.19	76.19	97.0	180	166	14.0	23.0	90.0	15.0
WPB 200 x 200 x 34.65	34.65	44.1	186	200	5.5	8.0	90.0	18.0
WPB 200 x 200 x 37.34	37.34	47.6	200	200	6.1	8.9	90.0	10.0
WPB 200 x 200 x 42.26	42.26	53.8	190	200	6.5	10.0	90.0	18.0
WPB 200 x 200 x 61.30	61.30	78.0	200	200	9.0	15.0	90.0	18.0
WPB 240 x 240 x 47.40	47.40	60.3	224	240	6.5	9.0	90.0	21.0
WPB 240 x 240 x 60.32	60.32	76.8	230	240	7.5	12.0	90.0	21.0
WPB 240 x 240 x 83.20	83.20	105	240	240	10.0	17.0	90.0	21.0
WPB 240 x 240 x156.68	156.68	199	270	248	18.0	32.0	90.0	21.0
WPB 300 x300 x100.85	100.85	128	294	300	10.0	16.0	90.0	27.0
WPB 300 x300 x117.03	117.03	149	300	300	11.0	19.0	90.0	27.0
WPB 300 x 300 x 237.92	237.92	303	340	310	21.0	39.0	90.0	27.0

SAIL ISMB ADDITIONAL INFORMATION

SAIL H BEAM is widely available in various grades such as AA, A, B, M. These are equivalent to the european standard of H Beam. The different standards and grades of H Beam comes with different features and applicabilities. It is also highlighted here in the important information about SAIL H Beam. Apart from that, different certifications like ISO and NABL compliance are also important for the quality assurance. The additional information on the iron tmt bar.

Authorised Approval	RDSO approved
Country Of Origin	Made in Bharat (INDIA)
Brand	SAIL - Steel Authority of India Limited (Nex)
Weather Resistance Grade	IS 11587 WR 480A & 480B
Test Certification	ISI Test Certificate & Mill TC Available
Grades	IS 2062 E250R, 300BR, 350BR, 410 BR & 450BR
Widely Used In	Metros, DFCC. RVNL, IRCON etc
Minimum Order Quantity (MOQ)	25 Metric Ton
Packaging Details	Bundles
Testominal of Usage	Electric Pole of Tata Power, Odisha & WBSEDCL.
